purchase best prices Helix by American Sportworks - 150cc 9.9 hp Assembled Full Suspension Go Kart
Special price Now!Offering all the sophistication of a high-performance ATV in a compact package, the Helix full-suspension go-kart is a great ride for people ages 12 and older. The Helix is outfitted with such features as a dual-wheel, automatic torque-converter drive that's perfect for hills, grass, mud, sand, and other tough terrain, along with a 150cc, 9.9-horsepower, air-cooled engine with an electric starter. As a result, the Helix not only holds up to heavy use and runs quietly, but it also zips around at up to 39 miles per hour--fast enough for all but the most reckless dune and trail riders (if that's too fast for your taste, a 20-mile-per-hour speed reduction kit is available). The Helix is also built for safety, with hydraulic disc brakes that stop quickly and three-point lap/shoulder belts to protect the passengers. And thanks to the independent front and semi-independent rear suspension, the Helix offers an extremely smooth ride.
Other features include an adjustable slide seat designed to accommodate one adult and one child or two children at once, aggressive 17-inch front and 18-inch rear tires for maximum traction, four adjustable coil-over hydraulic shocks for performance and versatility, a reverse gearbox for convenience, and such standard equipment as a rear rack, flag, enclosed drive train, and side splash guards. The Helix, which measures 34 to 39 inches from the seat back to the pedals, carries a one-year warranty on the engine.
Key Features:
- 150cc 4-stroke
- CVT automatic
- Integral reverse
- Electric start
- Full suspension
- Hydraulic brake
- 37-39 mph
- For ages 12 and over
Engine - Air Cooled, 4 cycle: Single Cylinder, 150cc
- Power (BHP @ RPM): 9.9 @ 7500
- Torque (Ft-lbs @ RPM): 13.0 @ 5500
- Starting System: Keyed Electric
- Ignition: CDI
- Exhaust System: Muffler with Heat Shield
- Fuel Capacity: 1.75 gallons
- Oil Capacity: 30 ounces 10W40
- Spark Plug: C7HSA (NGK)
Transmission
- Type: Dual Wheel Drive, CVT Automatic w/Reverse
- Chain Size: #50 5/8" Pitch
Tires & Wheels
- Front: 17 x 7 x 8 inches
- Rear 18 x 9.5 x 8 inches
Advanced Geometry Suspension
- Front: Dual A-arm with Coil-over Shocks
- Rear: Swing Arm with Coil-Over Shocks
- Steering: Chain Type
Frame
- Type: Heavy Gauge, Jig Welded 1-1/4" Main Frame
- Finish: Baked Powder Coat
Brakes
- Type 8.75" Hydraulic Disc with Parking Brake
Performance
- Maximum Speed (approximate): 37 to 39 mph
- Optional speed reducer: (20mph)
- Fuel Consumption: 30 to 50 mpg
- Terrain: Hills, slopes, grass, mud, and sand
Special Features
- Seat: Fingertip Adjustable Slide Seat
- Restraint System: 3-Point Shoulder/Lap Belts w/Retractor
- Engine: Stop Switch/Dual On Engine and Console
- Custom Bars: 1-1/4" Full Brush Bars
- Safety: Whip flag
- Guarding: Compliant to ASTM F2011
Dimensions
- Curb Weight: 436 pounds
- Maximum Rider Weight: 350 pounds
- Gross Vehicle Weight: 786 pounds
- Seat To Pedals: 34 to 39 inches
- Wheelbase: 74 inches
- Overall Vehicle Dimensions: 91 inches long x 47-1/4 inches wide x 55-3/8 inches tall
Manufacturer's Warranty
Engine - one year; frame, brush bars, spindles, seat frame - 90 days; all other components - 30 days
The latest deals, specials, and closeouts on Helix by American Sportworks - 150cc 9.9 hp Assembled Full Suspension Go Kart . The best quality and price on Helix by American Sportworks - 150cc 9.9 hp Assembled Full Suspension Go Kart Now Available In Stock & Super Save Shipping in USA. Get it now on sale for a cheap deal: Limit Time Offer.
Technical Details
- American SportWorks backs their product with an exclusive service warranty
- Please provide your phone # when ordering for all delivery communication
- American SportWorks backs their product with an exclusive service network - contact their customer service 1-800-643-7332 begin_of_the_skype_highlighting 1-800-643-7332 end_of_the_skype_highlighting begin_of_the_skype_highlighting 1-800-643-7332 end_of_the_skype_highlighting for any concerns
See more technical details
